AV Home Theater ReceiverNS-R5101AHD-AUser GuideNS-R5101AHD-A_10-0487_MAN_.book Page 0 Friday, May 7, 2010 7:51 AM

6Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comPlacing your speakers1 - Center speakerThis speaker enhances the front speaker

7Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.com• Pay close attention to speaker wiring polarity. In other words, connect posi

8Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comTo connect the antennas:1 Connect the FM antenna to your receiver.2 Connect th

9Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comDeciding which connections to useThe receiver supports several connection form

10Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comUsing the audio return channel (ARC) functionThe audio return channel (ARC) f

11Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comAV RecordingAudio sources can be recorded to a recorder (such as a cassette d

12Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comWhen you see the Rocketboost™ logo on any product, it has been designed to wo

13Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comEstablishing communicationsTo establish communications:1 Press the Power butt

14Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comTo install the batteries:1 Remove the cover.2 Insert two AA batteries into th

15Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comTo use Audyssey to set up and correct your speakers:1 Turn on the receiver an

iiwww.insigniaproducts.comContentsIntroduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

16Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comIf Subwoofer appears on the Review Speaker Configuration screen as No, increa

17Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comThe output is muted and the MUTING indicator flashes on the display.Using the

18Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.com5 Repeat steps 1 through 4 to preset your favorite radio stations.Tuning to a

19Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.com1 Dolby Digital is used for Blu-ray discs.2 The receiver can use the DSD sign

20Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comSpeaker layoutThe following shows the speakers that are activated in each typ

21Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comEach HDMI input can only be assigned to a single input selector. When HDMI1 -

22Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comUse the diameter of the smallest speaker in your system when choosing the cro

23Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comThe mono setting specifies the channel to be used for playing any 2-channel d

24Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comNoteAbout Audyssey Dynamic EQ®Audyssey Dynamic EQ® solves the problem of dete

25Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comAudio TV OUT (Audio TV Out submenu)This setting determines whether audio rece

iiiContentswww.insigniaproducts.comControlling other components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28Preprogrammed r

26Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comTV Control (TV Control submenu)Set to On when you want to control the receive

27Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.com•DTS•DTS Neo:6 Cinema•DTS 96/24•DTS-HD High Resolution•DTS-HD Master•DTS Expr

28Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comControlling other componentsYou can use your receiver’s remote control to con

29Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comRemote control codesInsignia Receiver Default 62472Zone 2 62545Tuner 52472Cab

30Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comTivo 01142, 01442Toshiba 00749, 01749Voom 00869SAT/PVR CombinationBell Expres

31Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comProscan 30522RCA 30522Samsung 30490, 30573, 33001, 32329, 32489, 32556Sharp 3

32Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comMaintainingTo clean this receiver, wipe with a soft, dry cloth. If the surfac

33Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comThere’s no sound with a certain signal format• Check the digital audio output

34Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comSpecificationsAmplifier sectionVideo sectionTuner sectionGeneral sectionWirel

35Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comLegal noticesFCC Part 15This system contains a NS-RB1 wireless audio sender/r

ivContentswww.insigniaproducts.comNS-R5101AHD-A_10-0487_MAN_.book Page iv Friday, May 7, 2010 7:51 AM

36Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comNS-R5101AHD-A_10-0487_MAN_.book Page 36 Friday, May 7, 2010 7:51 AM

37Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comOne-year limited warrantyInsignia Products (“Insignia”) warrants to you, the

www.insigniaproducts.com (877) 467-4289Distributed by Best Buy Purchasing, LLC7601 Penn Avenue South, Richfield, MN USA 55423-3645© 2010 BBY Solutions

1www.insigniaproducts.comInsignia NS-R5101AHD-AAV Home Theater ReceiverIntroductionCongratulations on your purchase of a high-quality Insignia product

2Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.com12 Use only with the cart, stand, tripod, bracket, or table specified by the m

3Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comComponentsFeatures• 90 Watts/Channel @ 8 ohms• Rocketboost™ Expandable Wireles

4Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comDisplayBackRemote control# Indicator1 Audio input indicator2 Listening mode in

5Insignia NS-R5101AHD-A AV Home Theater Receiverwww.insigniaproducts.comTop panel - NS-RB1Back panel - NS-RB1Setting up your home theater systemFindin
