Card description

# Feature Description

Status

indicator

The LED lights when your Rocketboost Wireless Card Ready

product is turned on and whenever there is a state change. After

5 seconds, the LED turns off and does not light again until there

is a state change. The LED shows the following state

information:

• Lights steadily when powered on and successfully joined or

connected to a Rocketboost network. The light is green if

your Rocketboost Wireless Card Ready product is configured

as a Hub device, otherwise the light will be blue.

• Blinks slowly when not connected to a Rocketboost network.

• Blinks rapidly when the Rocketboost Wireless Card Ready

product is in joining mode.

RF-RBCARD_10-0778_MAN_V2.fm Page 6 Tuesday, July 13, 2010 3:09 PM
