5RF-WHD200

Transmitter front/top panel

Item Description

1 HDMI 4—When the indicator is on this HDMI port is in use.

2 HDMI 3—When the indicator is on this HDMI port is in use.

3 HDMI 2—When the indicator is on this HDMI port is in use.

4 HDMI 1—When the indicator is on this HDMI port is in use.

Power and link status indicator ( )

• Blinking—The power is on and the receiver is searching for the transmitter or is in sleep

mode.

• On—The transmitter and receiver are linked.

• Off—The power is off.

RF-WHD200_10-1353_MAN_ENG_V3.fm Page 5 Monday, March 14, 2011 3:45 PM
