3RF-NBCAM

Web camera components

Setting up the Web camera

Installing the driver

Note: Install the driver first, then connect the Web camera to a USB port on your

computer.

Item Description Function

1 Snapshot button Use to capture still images.

2 LED indicator Turns on when the Web camera is connected.

3 Lens Provides the image to the Web camera.

4 Microphone Provides sound reception for the Web camera.

5 Removable base The base can be removed so you can clip the camera to your

notebook computer.
